If the Off Indicator Is Lit for an Adult-Size Occupant

Cadillac SRX / Cadillac SRX Owners Manual / Seats and Restraints / Airbag System / Passenger Sensing System / If the Off Indicator Is Lit for an Adult-Size Occupant

border=0>

If a person of adult-size is sitting in the front outboard passenger seat, but the off indicator is lit, it could be because that person is not sitting properly in the seat.

Use the following steps to allow the system to detect that person and enable the front outboard passenger frontal airbag and seat-mounted side impact airbag:

1. Turn the vehicle off.

2. Remove any additional material from the seat, such as blankets, cushions, seat covers, seat heaters, or seat massagers.

3. Place the seatback in the fully upright position.

4. Have the person sit upright in the seat, centered on the seat cushion, with legs comfortably extended.

5. Restart the vehicle and have the person remain in this position for two to three minutes after the on indicator is lit.
